Aprilent Systems

MATRIX SPARSHVP210

Technical Specifications

Audio Features

  • Codec: G.722, G.711(A/µ), G.729, G.723
  • DTMF: In-band, Out-of-band (RFC 2833)
  • SIP INFO
  • Full-duplex hands-free speakerphone with AEC, VAD, CNG, AEC, AJB, AGC

Phone Features

  • Abbreviated Dialing, Call Pick Up and Internal Call Restriction
  • Call Hold, Mute and DND
  • One-touch Transfer and Hotline
  • Redial, Auto Call Back (ACB) and Auto Answer
  • Call Forward, Call Waiting and Call Transfer
  • 3-way Conferencing and Multi-party Conference
  • Emergency Call and Conferencing

Display

  • 128 x 64 Graphical LCD
  • LED for Call, Message Wait Indication
  • Intuitive user interface with Icon

Interface

  • 2 x RJ45 10/100/1000 Ethernet Ports
  • Power over Ethernet (IEEE 802.3af)
  • 1 RJ9 Handset Port
  • 1 RJ9 Headset Port
  • 1 3.5mm Headset Port
  • DC Power Jack
  • Operating Humidity: 5-95 %
  • Operating Temperature: 0 °C to 45 °C

Networking and Security

  • Extended (Proprietary) SIP Protocol
  • IP assignment: Static, DHCP, SRTP, TLS
  • QoS: 802.1p/Q tagging (VLAN)

Physical Features

  • Desk mount
  • External AC Adaptor (Optional): AC 100~240V Input & DC 5V/600mA output
  • Dimension (W x H x D): 163 x 210 x 101 mm

Installation

  • Desk mount

Environmental

  • Operating Temperature: 0° C to 45°C
  • Operating Humidity: 10 – 95% (Non-condensing)

Certifications

  • CE, FCC-15 (Class B), RoHS
